Connectors & Buttons
■ Back panel
- 1x PS/2 keyboard/ mouse combo port
- 4x USB 2.0 ports
- 1x Clear CMOS button
- 1x Coaxal S/PDIF-out port
- 1x Optcal S/PDIF-out port
- 1x LAN port
- 2x USB 3.0 ports
- 1x HDMI port**
- 1x VGA port**
- 1x DVI-D port**
- 6x flexble audo ports
**(The HDMI, DVI-D and VGA ports only work wth Integrated Graphcs Processor)
■ On-Board
- 4x USB 2.0 connectors
- 1x USB 3.0 connector
- 1x Chasss Intruson connector
- 1x S/PDIF-Out connector
- 1x Front Panel Audo connector
- 1x TPM Module connector
- 1x Seral port connector
- 1x DLED3 connector (optonal)
Slots
■ 2x PCIe 3.0 x16 slots
- PCI_E2 supports up to PCIe x16 speed (when PCI_E5 s empty) or PCIe x8 speed
(when PCI_E5 s nstalled)
- PCI_E5 supports up to PCIe x8 speed
■ 3x PCIe 2.0 x1 slots
■ 2x PCI slots

Form Factor

■ ATX (24.4 cm X 30.5 cm)
Mountng Screw Holes
■ 9x mountng holes
If you need to purchase accessores and request the part numbers, you could search
the product web page and find detals on our web address http://www.ms.com/ndex.
php
En-3
