Ohms
RANGE
400.0Ω
4.000kΩ, 40.00kΩ,
400.0kΩ
4.000MΩ
40.00MΩ
Open Circuit Voltage : 0.4VDC typical
Capacitance
RANGE*
500.0nF, 5.000μF,
50.00μF, 500.0μF,
3000μF
*Additional 50.00nF range accuracy is not specified
**Accuracies with film capacitor or better
***Specified with battery voltage above 2.8V (approximately half full battery). Accuracy
decreases gradually to 12% at low battery warning voltage of approximately 2.4V
Hz Frequency
Function Sensitivity
(Sine RMS)
400.0mV 150mV
4.000V 3.2V
40.00V 25V
400.0V 100V
600V 400V
1)
400.0μA 500μA
1)
2000μA 500μA
2) 3)
400.0A 60A
Display counts: 5000
Best resolution: 0.001Hz
Accuracy: 0.5%+4d
1)
Available to Models 127M & 128M only
2)
Available to Models 111M & 112M only
3)
Unspecified for Model 110M
Diode Tester
Open Circuit Voltage Test Current
< 1.6 VDC
DC μA (Models 127M & 128M only)
RANGE Accuracy
1.5% + 4d
400.0μA
1.2% + 3d
2000μA
All manuals and user guides at all-guides.com
Elma 3036 + 3038 + BM126
Accuracy
0.8% + 6d
0.6% + 4d
1.0% + 4d
2.0% + 4d
Accuracy**
3.5%*** + 6d
Range
10Hz -- 2kHz
5Hz -- 40kHz
5Hz -- 100kHz
5Hz -- 100kHz
5Hz -- 5kHz
10Hz ~ 30kHz
10Hz ~ 30kHz
40Hz ~ 400Hz
(Typical)
0.25mA
Burden
Voltage
2.8mV/μA
2.8mV/μA
