Pull the safety bond through the attachment eyelet and over the trussing system or a safe fixation spot.
Insert the end in the quick link and tighten the safety screw.
The maximum drop distance must never exceed 20 cm.
A safety bond which already held the strain of a crash or which is defective must not be used again.
Adjust the desired inclination-angle via the mounting-bracket and tighten the fixation screws.
Before taking into operation for the first time, the installation has to be approved by an expert!
Connection with the mains
Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection cables is as follows:
Cable
Pin
Brown
Live
Blue
Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
OPERATION
After you connected the effect to the mains, the LED CPE-40 IR Flower Effect starts running.
The device can now be operated via the enclosed remote control.
Remote Control
The remote control is supplied with a battery inserted. An insulating foil between the battery and the
1
battery contacts prevents the battery from being discharged during storage. Prior to the first operation
remove the foil from the battery support on the rear side of the remote control. Otherwise operation of
the remote control is not possible.
When actuating a button, always hold the remote control in the direction of the sensor (centrally located
2
on the device front). There must be visual connection between the remote control and the sensor.
If several systems are to be controlled by a single remote control, position the control units with their
3
sensors close to each other.
If the range of the remote control decreases (8 meters as a maximum), replace the battery. For this
4
purpose, on the rear side of the remote control press the small bar with the groove
to the right and at the same time remove the battery support.
For operation, one 3 V button cell type CR 2025 is required. When inserting, pay attention that the
5
positive pole of the button cell shows upwards in the support.
Danger of explosion when battery is replaced improperly. Only replace by the same type. Please
dispose of old and used batteries properly. Batteries are hazardous waste and should not be
disposed of with regular domestic waste!
DANGER TO LIFE!
International
L
N
CAUTION!
14/16
00082026, Version 1.0
