The Doxa Sub Bezel; The Doxa Sub Models - Doxa SUB 200 T.GRAPH Bedienungsanleitung

THE
DOXA
SUB
BEZEL
DOXA's patented SUB
bezel uses the US Navy's
no-decompression table
to calculate the safe dive
time for a given depth
without a decompression
stop during the return
to the surface.
The Outer Ring shows
given dive depths in feet
or meters ("FT" means
the depth is measured
in feet). The Inner Ring
shows the time in
minutes at the depths
indicated above on the
outer ring. The Descent
Marker (two dots on the
bezel) is used to set your
Example
watch for the dive
It's 13:24 hrs and the
duration starting at the
deepest you intend
current time. Once it's
Minute Hand to go is 100 feet
set, the
(30 meters). Your SUB
will also indicate the
will tell you how long
number of minutes you
you can stay there
may remain at the
without having to stop
desired depth and return
on the way up.
to the surface without a
decompression stop.
1. Turn the bezel to align
the Descent Marker with
the minutes of the
current time (13:24).
14
2. Look up 100 ft/30 m on
the outer ring: The inner
ring shows a safe dive
time of 25 minutes.
3. Once you've arrived
at your dive depth, keep
monitoring the minute
hand. Commence your
ascent at 13:49 (13:24 +
25 minutes).

THE DOXA SUB MODELS

MODEL MOVEMENT
SUB 200 Swiss automatic
SUB 300T Swiss automatic
Swiss
SUB 200 T.GRAPH mechanical,
Valjoux 7734
SUB 1500T Swiss automatic
SUB 4000T Swiss automatic
POWER
FUNCTIONS
RESERVE
Hours, minutes, seconds, date 38 hours
Hours, minutes, seconds, date 38 hours
Hours, minutes, seconds, date,
45 hours
chronograph
Hours, minutes, seconds, date 42 hours
Hours, minutes, seconds, date,
42 hours
power reserve indicator
15
