Intenso XS5000 Bedienungsanleitung Seite 13

USE
Device overview
1 - Function key (ON/OFF)
2 - USB-A Out
3 - USB-C In/Out
4 - microUSB In
5 - Status LEDs
Operation
Function key (On/Off)
By briefly pressing the key, the current battery status is displayed through the LED lights and the Power-
bank is activated.
If no device is connected to the Powerbank, or the connected device is fully charged, the Powerbank chan-
ges automatically into standby mode after a time interval of approx. 30 seconds.
LED Status display
If no device is connected to the Powerbank, or the connected device is fully charged, the Powerbank chan-
ges automatically into standby mode after a time interval of approx. 30 seconds.
% - Energy
1 % - 25 %
26 % - 50 %
51 % - 75%
76 % - 100 %
Commissioning / Charging the Powerbank / Charging connected devices
a) Charging the Powerbank
Please connect the supplied USB-A to USB-C cable with the USB-C connection (USB-C In/Out) of the Pow-
erbank and connect the opposite end of the USB cable with the Standard USB Port of a computer or USB
power supply. You can also use a USB-A to microUSB cable to charge the Powerbank through the microUSB
connection (microUSB In). Always use only one of the two charging options, the USB-C port (USB-C In/Out)
or the microUSB port (microUSB In)!
The charge process and the current charge status is signalled by the LED status lights. If the Powerbank
is fully charged, the LED status lights are lit permanently. The required charging time of the Powerbank is
dependent on the selected charging source and its output power (microUSB In max. 5V - 2.1A; USB-C In/
Out max. 5V - 2.1A).
1
LED 1 LED 2
EN - Page 4 of 6
2 3 4
LED light
LED 3
5
LED 4
