6. Putting into operation

NC tamper
Tam per Output
output
(0.5A, 24V N.C)
Anti Approach
Output
(0.1A, 24V N.C)
Trouble Output
Trouble output
70 m A m ax
Sounder input +
+ 12 V
Sounder input - COM(-)
COM(-)
Strobe input -
IMPORTANT:
Before connecting, make sure that the power supply is switched off!
6.1

LED indication

LED
POWER
LED2
Power
supply
Optional
(optional)
13.8VDC
1.6 A
TAM PER
BLK
INT EXT
(To Int.
JP3
Tam per)
TRIG STRO B
C - AUTO
C + M AN
O N
1 2 3 4
CONFIG
LED2
Description
The power LED shows the operating state of the
sounder.
ON: Power supply is applied to the sounder.
OFF: No power supply to the sounder.
FLASHING: Sounder trouble.
Status LED
ON: Input signal at LED input.
OFF: No signal at input.
IMPORTANT:
The signal to the LED is user-defined, e.g.: alarm
system set. But you can also combine the input of the
Status LED with the output of the fault output (TRBL).
Battery
To
Battery
RED
POW ER
ON
1 2 3 4
ID1
Sounder
To Internal
speaker
Speaker
Power supply
13.8VDC ,
200 mA (m ax)
Status LED2
Status LED
On/Off
13
