Clean the filters weekly.
Warning:
Do not use the appliance without the filter system.
Note:
Clean filters make sure that your appliance functions correctly.
1. Remove the lower basket.
2. Turn the main filter (A) counter-clockwise to remove it.
Note:
The micro filter and the sieve are attached to the main filter.
3. Remove the micro filter (A) from the filter assembly (B).
4. Turn the main filter (A) counter-clockwise to remove it.
5. Clean the main filter, the micro filter and the sieve. Use warm water and a dishwasing brush.
6. Install the sieve.
7. Install the main filter into the micro filter. Make sure that the markers are aligned.
8. Install the main filter into the sieve.
9. Turn the main filter (A) clockwise to fasten it.
Caution:
Make sure that the filters are placed correctly. Incorrect placement of the filters affects the maximum
performance of the appliance.

CLEANING THE SPRAY ARMS

1. Hold the nut (A) in the center still and rotate the upper spray arm (B) counter clockwise.
2. Pull the lower spray arm (A) upwards to remove it.
3. Clean the spray arms. Use soapy and warm water and use a soft brush to clean the jets.
4. Hold the nut (A) in the center still and rotate the upper spray arm (B) clockwise.
5. Push the lower spray arm (A) down to put it back.
7

Extra information

WATER HARDNESS LEVEL SETTINGS (SALT CONSUMPTION)
German hardness
Level
[dH]
H1 0-5
H2 6-11
H3 12-17
H4 18-22
French hardness [dF] British hardness [dE]
0-9 0-6
10-20 7-14
21-30 15-21
31-40 22-28
(Figure 21)
(Figure 22)
(Figure 23)
(Figure 24)
(Figure 25)
(Figure 26)
(Figure 27)
(Figure 28)
Program selector button on
Quick '30, on
Quick '90, on
Quick '90 and Quick '30, on
Eco, on
