Item
Position of outlet hose
Length of outlet hose [m]
4
Description
INTENDED USE
The appliance is intended to wash dishes.
Do not use the appliance for any other purpose than described in this document.
BUILT-IN DISHWASHER
(Figure 1)
A
Nozzle of the cutlery drawer
B
Spot
C
LED indicator
D
Cutlery drawer
E
Upper basket
F
Lower basket
G
Rating plate
Item
Nozzle of the cutlery drawer
Spot
LED indicator
Cutlery drawer
Upper basket
Lower basket
Rating plate
Control panel
Detergent and rinse aid reservoir
Cutlery basket
Salt reservoir
Filters
Lower spray arm
Upper spray arm
Specification
Left rear
1.40
H
Control panel
I
Detergent and rinse aid reservoir
J
Cutlery basket
K
Salt reservoir
L
Filters
M
Lower spray arm
N
Upper spray arm
Function
To clean the dishes in the cutlery drawer.
To provide light inside the appliance during loading and
unloading:
•
The spot comes on when the door is open.
•
The spot goes off when the door is closed.
•
When the appliance is in standby, the spot goes off 4
minutes after opening the door. If you push a button
during this time, the spot comes on again.
To show the state of the appliance.
The LED indicator projects a light on the floor.
Loading the appliance
Refer to section
Loading the appliance
Refer to section
Loading the appliance
Refer to section
To show the specifications of the appliance.
Refer to section
Control panel
To hold the detergent and rinse aid.
Loading the appliance
Refer to section
To hold the salt.
To keep the appliance free from contamination.
To clean the dishes in the lower basket.
To clean the dishes in the upper basket.
.
.
.
.
.
