OVERVIEW OF THE MONITOR:
1 2 3
1.
Display (LCD screen)
2.
Charging LED RED when mains power connected.
3.
Parent Unit ON/OFF LED (Green)
4.
Sound Level indicators (Green, Amber, Red, Red) Show the sound level detected by the Baby Unit the
louder of sound detected, the more LEDs light up.
5.
Volume - Press to decrease Volume level.
6.
Volume + Press to increase Volume level.
7.
Display ON/OFF button
8.
Microphone
9.
MENU button
10. Navigation button
11. OK button
12. TALK button Press and hold to speak to your baby.
13. Power button
14. Antenna
15. RESET pin hole (recessed - use small pin)
16. Speaker
17. Power Socket
18. Stand
IMPORTANT GUIDELINES FOR INSTALLING YOUR BABY MONITOR
•
To use your camera (baby unit) and the monitor (Parent Unit) together, you must be able to
establish a radio link between them, and the range may be affected by environmental
conditions.
•
Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or rein-
forced concrete between the camera and the monitor may block the radio signal.
•
The signal strength may also be reduced by other solid structures, like walls or electrical
equipment, such as radios, TVs, computers, cordless or mobile phones, fluorescent lights or
dimmer switches.
•
Use of other 2.4 GHz products, such as wireless networks (Wi-Fi® routers), Bluetooth® systems,
or microwave ovens, may cause interference with this product, so keep the Baby Monitor at
least 1.5 metres (5 feet) from these types of products, or turn them off if they appear to be
causing interference.
•
If the signal is weak, try moving the monitor and/or the camera to different positions in the
rooms.
LUVION
Premium Baby products
4 5 6 7
Press to turn the LCD screen ON/OFF (Note: audio is maintained.)
Press to open / close the Menu options.
Move Up/Down/Right/Left menu options.
Press and Hold to turn the Parent Unit ON/OFF.
8
9
10
11
12
13
14
5
15
16
17
18
