INSTALLATION INSTRUCTIONS
CONTROL WITH
2 BUTTONS FOR
730 - 739
ALL OUTPUTS
740 - 741
742
DIMMER ON/OFF
743 - 749
800 - 805
RGB / RGBW
SEQUENCER
806 - 809
DYNAMIC WHITE 810 - 819
820 - 821
822
DIMMER
ON/OFF/10%
823 - 829
830 - 831
CONTROL WITH
832
SINGLE
PUSH BUTTONS
833 - 839
600 - 629
REPLICATE
700 - 749
OUTPUT ON DMX
800 - 839
p1 = briefly press push button;
Symbols used:
pp1 = briefly press twice push button 1;
P1 = press and hold push button 1;
p1 + p2 = simultaneously press push buttons 1 and 2;
// = parallel;
inc/dec = increases/decreases;
p1 (outputs "on") = press p1 with outputs "on".
L&L Luce&Light srl / Via Trescalini, 5 / 36031 Dueville, Vicenza / Italy / T +39 0444 36 05 71 / F +39 0444 59 43 04
BTN UP/DOWN
Push buttons on
250MA
T.34C
inputs 2 and 3
1 push button
BUTTONS
250MA
T.34C
2 push buttons
3 push buttons
3ch RGB
SEQUENCER
250MA
T.34C
3ch RGBW
DYN WHITE
250MA
T.34C
ON / OFF / 10%
250MA
T.34C
BUTTONS
250MA
T.34C
DMX master
Mode
E lucelight@lucelight.it / www.lucelight.it
Push button 2 increases all the outputs in //
Push button 3 decreases all the outputs in //
Push button 1 controls all the outputs in //
Push button 1 controls outputs 1 and 2
Push button 2 controls outputs 3 and 4
Push button 1 controls output 1
Push button 2 controls output 2
Push button 3 controls output 3
Push button 2 + 3 controls output 4
Push button 1
p1 = outputs on/off
pp1 = maximum intensity
P1 (outputs "on") = inc/dec intensity
P1 (outputs "off") = "on" with 10% intensity
Push button 2
p2 = starts/stops colour rotation
P2 (outputs "off") = changes rotation speed
Push button 3
p3 = white/colour
pp3 = maximum saturation
P3 (outputs "off") = changes saturation
P3 (outputs "on") = minimum saturation
Push button 1
p1 = outputs "on"/"off"
pp1 = max intensity
P1 (outputs "on") = inc/dec intensity
P1 (outputs "off") = 10% intensity
Push button 2
P2 (outputs "on") = inc/dec colour temperature
Push button 1 controls all the outputs in //
Push button 1 controls outputs 1 and 2
Push button 2 controls outputs 3 and 4
Push button 1 controls output 1
Push button 2 controls output 2
Push button 3 controls outputs 3 + 4
pp = maximum intensity
P (outputs "on") = inc/dec intensity
P (outputs "off") = "on" at 10% intensity
Push button 1 controls all the outputs in //
Push button 1 controls outputs 1 and 2
Push button 2 controls outputs 3 and 4
Push button 1 controls output 1
Push button 2 controls output 2
Push button 3 controls outputs 3 + 4
In all modes within the specified parameter ranges, the
output can be replicated on one or more SLAVE devices
connected in DMX and set as follows:
- Linear RGBW personality = RGBW PLAIN
- Start address = 1
ARCUNID2-01
7/8
