INSTALLATION INSTRUCTIONS
Nominal supply voltage
Supply voltage range (min–max)
Max. output voltage (LED Vf)
Output current
Max power per output
Selectable current levels
PWM frequency
Current control resolution
Operating temperature
Protections
Total max. power RGB (1.05A)
Total max. power RGBW (1.05A)
(*) There must always be a minimum voltage difference of 5V between input and output (dropout) in order for the driver to function
correctly.
If the dropout is not respected, the open circuit protection is triggered: the input power supply must be removed to restore oper-
ation.
Operating Modes
To activate the various operating modes, you must set the corresponding mode via the Contraves devices (2), while the Con-
traves device (6) sets the operating current independently.
The display (8) shows the status of the set mode and current as well as the detected temperature:
Current setting:
The current is set via the associated Contraves device (6) to one of the following preset values:
Table 1: Current value setting
#
0
Current
250mA
DALI (DT6) mode:
Use the three Contraves devices (2) to set a value between
DMX-RDM mode:
With the board switched off:
-
if you set a value between
-
if you set a value of 0 or a value between
first DMX channel by sending it via RDM command.
0–10V inputs:
You can select from 1 to 3 0–10V inputs by setting the following values:
600-601:
1 input (controls all the outputs);
602:
2 inputs (the first controls outputs 1 and 2; the second controls outputs 3 and 4);
from 603 to
609:
3 inputs (the first controls output 1; the second, output 2; the third, outputs 3 and 4).
L&L Luce&Light srl / Via Trescalini, 5 / 36031 Dueville, Vicenza / Italy / T +39 0444 36 05 71 / F +39 0444 59 43 04
Main electrical characteristics
Mode
set (2)
Current
set (6)
1
2
300mA
350mA
425mA
1 and
512, using the three Contraves devices, the address of the first DMX channel will be the corresponding set value;
513 and
E lucelight@lucelight.it / www.lucelight.it
24 - 48 Vdc
20 ÷ 52 Vdc
Vin – 5V max (*)
250 ÷ 1050 mA max per channel
20W (@24V); 45W(@48V) max per channel
250, 300, 350, 425, 500, 600, 700, 800, 900, 1050mA
2,9 kHz
14bit
0 ÷ 40 °C
Open circuit, short circuit, overtemperature
60W (@24V); 135W(@48V)
80W (@24V); 180W(@48V)
PALETTE 4
250MA
T.35C
3
4
5
500mA
600mA
900 and
999.
599, with the three Contraves devices, you can select the address of the
ARCUNID2-01
Temperature
detected
6
7
700mA
800mA
900mA
8
9
1050mA
3/8
