INSTALLATION INSTRUCTIONS
A long press on push button 2 increases or decreases the intensity of the output, while pressing push button 1 for about 1.5
seconds switches off the driver's outputs. These can be reactivated with a short press of the same button.
When switched back on, the default colour/show and intensity are restored.
Control using two push buttons to drive all the outputs:
Setting a value between
the intensity of all outputs in parallel.
Control using individual push buttons:
You can select from 1 to 3 push buttons using the following values:
from 740 to 741 :
push button 1 controls all the outputs in parallel;
742 :
push button 1 controls outputs 1 and 2, push button 2 controls outputs 3 and 4;
from 743 to 749 :
push button 1 controls output 1, push button 2 controls output 2, and push button 3 controls output 3. Output
4 is controlled by pressing buttons 2 and 3 simultaneously.
Short press: switches the associated outputs on/off.
Long press: increases/decreases the intensity of the associated outputs.
RGB/RGBW sequencer:
To select this mode, set a value between
- The values between
800 and 805
- The values between
806 and 809
Push buttons functions:
1:
- switches outputs on/off (short press);
- maximum intensity (two short presses);
- increases/decreases intensity (long press with outputs switched on);
- switch-on with 10% intensity (long press with outputs switched off).
2:
- starts/stops colour rotation (short press);
- changes rotation speed (long press with outputs switched off).
3:
- white/colour (short press);
- maximum saturation (two short presses);
- changes saturation (long press with outputs switched off);
- minimum saturation (long press with outputs switched on).
Dynamic white:
To select this mode, set a value between 810 and 819 with the Contraves devices.
Push button functions:
1:
- switches outputs on/off (short press);
- maximum intensity (two short presses);
- increases/decreases intensity (long press with outputs switched on);
- switch-on with 10% intensity (long press with outputs switched off).
2:
- increases/decreases temperature colour (long press with outputs switched on).
Dimmer – on/off – 10% on three push buttons:
You can select from 1 to 3 push buttons using the following values:
820-821:
push button 1 controls all the outputs in parallel;
822:
push button 1 controls outputs 1 and 2, push button 2 controls outputs 3 and 4;
from 823 to 829:
push button 1 controls output 1, push button 2 controls output 2, and push button 3 controls outputs 3 and 4.
Short press: switches the associated outputs on/off.
Two short presses: maximum intensity.
Long press with outputs switched on: increases/decreases intensity.
Long press with outputs switched off: switch-on with 10% intensity.
On/off on three push buttons:
You can select from 1 to 3 push buttons using the following values:
830-831:
push button 1 controls all the outputs in parallel;
832:
push button 1 controls outputs 1 and 2, push button 2 controls outputs 3 and 4;
from 833 to 839:
push button 1 controls output 1, push button 2 controls output 2, and push button 3 controls outputs 3 and 4.
By briefly pushing a button, you can switch the associated outputs on/off.
L&L Luce&Light srl / Via Trescalini, 5 / 36031 Dueville, Vicenza / Italy / T +39 0444 36 05 71 / F +39 0444 59 43 04
730 and 739
enables the mode that increases (using push button 2) or decreases (using push button 3)
800 and 809
only use the 3 RGB channels;
use 4 RGBW channels.
E lucelight@lucelight.it / www.lucelight.it
with the Contraves devices:
ARCUNID2-01
5/8
