INSTALLATION INSTRUCTIONS
1–9V inputs:
You can select from 1 to 3 inputs 1-9V by setting the following values:
610-611: 1 input (controls all the outputs);
612: 2 inputs (the first controls outputs 1 and 2; the second controls outputs 3 and 4);
from 613 to 619: 3 inputs (the first controls output 1; the second, output 2; the third, outputs 3 and 4).
22 kOhm potentiometer:
You can select from 1 to 3 potentiometers (22 kOhm) using the following values:
620-621: 1 potentiometer (controls all the outputs);
622: 2 potentiometers (the first controls outputs 1 and 2; the second controls outputs 3 and 4);
from 623 to 629: 3 potentiometers (the first controls output 1; the second, output 2; the third, outputs 3 and 4).
Fixed colour palette*:
By setting a value between
700 – yellow
701 – cyan
702 – green
703 – magenta
704 – red
705 – blue
706 – turquoise
707 – orange
708 – white (rgb)
709 – white (rgbw)
710 – white (just w)
Show*:
By setting a value between
711 – RGBW show (5 sec transition, 5 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta+W, white, yellow+W
712 – cool colours show (10 sec transition, 2 sec dwell time)
cool white, cyan, blue
713 – warm colours show (10 sec transition, 2 sec dwell time)
warm white, orange, yellow
714 – RGB show (20 sec transition, 5 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
715 – RGBW show (10 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
716 – RGB show (5 sec transition, 2 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
717 – RGBW show (40 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
718 – RGBW show (20 sec transition, 2 sec dwell time)
red, green, blue, just W, red+W, green+W, blue+W,
magenta, yellow, cyan, cyan+W, magenta + W, white, yellow+W
719 – RGB show (40 sec transition, 2 sec dwell time)
red, green, blue, magenta, yellow, cyan, white
720 – rapid RGB show (2 sec transition, 2 sec dwell time)
red, green, blue
*Using the push buttons with fixed colour palette and shows:
In the two previous cases (with the Contraves devices set between
to the next step as if increasing the value selected by the Contraves devices by one unit: the cycle includes all fixed colour pal-
ettes and shows regardless of which of the two modes you started from. With this functionality, the value given by the Contraves
devices only establishes the initial step (colour/show).
L&L Luce&Light srl / Via Trescalini, 5 / 36031 Dueville, Vicenza / Italy / T +39 0444 36 05 71 / F +39 0444 59 43 04
4/8
700 and 710, you can select one of the following fixed colours:
R=255 G=255
R= 0 G=255
R= 0 G=255
R=255 G= 0
R=255 G= 0
R= 0 G= 0
R= 0 G=255
R=255 G=153
R=255 G=255
R=255 G=255
R= 0 G=0
711 and 720, you can select one of the ten pre-programmed shows (maximum intensity in each):
E lucelight@lucelight.it / www.lucelight.it
B= 0 W= 0
B=255 W= 0
B= 0 W= 0
B=255 W= 0
B= 0 W= 0
B=255 W= 0
B=182 W= 0
B= 0 W= 0
B=255 W= 0
B=255 W=255
B= 0 W=255
700 and 720) you can use push button 1 to advance cyclically
