INSTALLATION INSTRUCTIONS
Replicating the output on DMX (Master DMX Mode)
When the control unit works with the functionalities defined by Contraves values between:
- 600 and 629;
- 700 and 749;
- 800 and 839;
the output can be replicated on one or more connected DMX devices (which function as slaves).
For the system to function correctly, DMX devices must be set with:
- linear RGBW personality (RGBW PLAIN);
- start address = 1.
NOTES:
•
If, at switch-on, you set a value other than those listed above with the selectors, DMX mode with address set via RDM com-
mand is selected.
Table 2 - Summary table of operating modes
Mode
Param.
DALI (DT6)
900 - 999
1 - 512
DMX-RDM
0 or
513-599
600 - 601
INPUTS
602
0 - 10V
603 - 609
610 - 611
INPUTS
612
1 - 9V
613 - 619
620 - 621
POTENTIOMETERS
622
(22K)
623 - 629
FIXED COLOUR
700 - 710
PALETTE
PRE-
PROGRAMMED
711 - 720
SHOWS
L&L Luce&Light srl / Via Trescalini, 5 / 36031 Dueville, Vicenza / Italy / T +39 0444 36 05 71 / F +39 0444 59 43 04
6/8
Display
Config.
DALI 0 1 2 3
250MA
T.34C
DMX ADDRESS xxx
250MA
T.34C
xxx=address
ch1 DMX
1 X 0-10V
1 input
250MA
T.34C
2 X 0-10V
2 inputs
250MA
T.34C
3 X 0-10V
3 inputs
250MA
T.34C
1 X 0-9V
1 input
250MA
T.34C
2 X 0-9V
2 inputs
250MA
T.34C
3 X 0-9V
3 inputs
250MA
T.34C
1 X POT 22K
1 potentiometer
250MA
T.34C
2 X POT 22K
2 potentiometers
250MA
T.34C
3 X POT 22K
3 potentiometers
250MA
T.34C
PALETTE #
250MA
T.34C
2 push buttons
#=1,2,...,11
number of palette
set
SHOW #
250MA
T.34C
2 push buttons
#=1,2,...,10
number of show
set
E lucelight@lucelight.it / www.lucelight.it
Description
CH1 DMX address = value set
by Contraves device (1–512)
CH1 DMX address set via
RDM command (default 001)
Input 1 controls all the outputs
Input 1 controls outputs 1 and 2
Input 2 controls outputs 3 and 4
Input 1 controls output 1
Input 2 controls output 2
Input 3 controls outputs 3 and 4
Input 1 controls all the outputs
Input 1 controls outputs 1 and 2
Input 2 controls outputs 3 and 4
Input 1 controls output 1
Input 2 controls output 2
Input 3 controls outputs 3 and 4
Potentiometer 1 controls all the outputs
Potentiometer 1 controls outputs 1 and 2
Potentiometer 2 controls outputs 3 and 4
Potentiometer 1 controls output 1
Potentiometer 2 controls output 2
Potentiometer 3 controls outputs 3 and 4
Set the fixed colour palette according to
Table 3
See notes (*)
Set the pre-programmed shows according to
Table 4
See notes (*)
ARCUNID2-01
