3.4 Remote control pairing
In order to activate the pairing function, press and rele-
ase the 'REMOTE SET' button on the control unit,
after which a red LED will fl ash on the con-
trol unit. Now long press (3 seconds)
one of the active remote control but-
tons.
Multiple control units can be
paired and used with a single
remote control.
Multiple remote controls can
be paired and used with the
same control unit.
Pairing must not be activated during
the track memorization cycle.
To unpair the remote control
from the control unit, press
and release the 'REMOTE
SET' button, after which the red LED will fl ash. Press the 'REMOTE SET' but-
ton again and keep it pressed until the led stops fl ashing. When the button
is released, the red LED will fl ash 5 times to confi rm the unpairing.
The unpairing of a remote control completely eliminates its association with
any control unit. In order to use the remote control, it will be necessary to
pair it again using the standard procedure.
3.5 Wiring of the control unit switch
DEVICE = 0 - 48V
MAX 2A
The NO switch is a simple, normally open contact controlled by control unit.
No voltage output is supplied from the switch terminals.
The switch can control equipment with a nominal voltage of between 0
and 48V and a maximum current of 2A.
Wiring for control via the switch must be performed by specialized per-
sonnel according to the wiring diagram supplied.
00:00:03
FREQUENCY: 433,92 MHZ
MAX POWER: 1 mW
