A/ Writing of a number without a decimal point:
When the dashes are displayed, pressing a horizontal shift key replaces the dashes by zeros, by the
value previously recorded, or by the extreme value possible compatible with the function. The value of
the active digit (flashing) is incremented or decremented by pressing the
key, respectively. Increasing a digit from 9 to 0 automatically increments the digit (or digits) to the left of
it, while decreasing a digit from 0 to 9 automatically decrements the digit (or digits) to the left of it.
Example :
If during the incrementation or decrementation operations the maximum display capacity is exceeded,
the display unit reverts to displaying five dashes.
The
to the left or to the right, respectively.
When the left-hand digit is active, pressing the
dashes or of the value previously recorded in memory.
Validation is effected by pressing the
Validating "-----" stops and cancels all programming.
B/ Positioning of the decimal point:
To activate the decimal point, you must press the
Pressing the
or key can then be pressed to set the dcimal point to desired position.
When the decimal point is located on the left or right side of the display unit, pressing
the
00.561.8187
1. Display
2. Key
3. Display
and keys are used to shift the active digit (flashing), the one to be programmed,
key again activates the shifting of the decimal point. The
Example :
1. Display
2. Key
3. Display
4. Key
5. Display
or key, respectively, causes the appearance of „-----".
www.
key causes the appearance of the five
key or another programming key (e.g. SCAN).
key until the right-hand digit flashes.
