Consider the camera and motion detection angles when choosing a location. Test this before
drilling holes and mounting.
Do not mount the camera behind glass. Glare from infrared LED lights may overexpose the
image.
1. Use the holes on the mounting plate as a template to mark where to drill.
2. If needed, insert the plastic dowels using a mallet.
3. Fix the mount to the wall using the supplied screws.
4. Screw the device onto the mount, making sure the rubber gasket forms a good seal around the mount-
ing points.
5. Make sure the device is securely attached to the mounting bracket before letting go.
Operation
A) Power ON
• Press and hold the power button to turn the camera ON.
B) Pairing mode
• If the camera is not paired with the app:
- You will hear a voice prompt that the camera is ready to pair.
- The LED status indicator will flash blue.
• If the camera is already paired with the app:
- The LED status indicator will be solid blue
- The camera will function as usual.
C) Reset the camera
Perform a reset if the camera is not functioning correctly or you would like to enter pairing mode.
1. Insert the included reset pin into the reset hole.
2. Press down until you feel a "click" then hold 4-5 seconds.
3. Stop pressing when you hear the voice prompt "system reset ...".
D) Power OFF
• If you continue to press and hold reset after the prompt has sounded, the device will power off.
Low light recording
The device is equipped with a light sensor that automatically triggers "night vision" when ambient
light falls below a certain level.
The recorded image will be in black and white.
Motion detection
• With a microSD card inserted:
- 15 second clips will be saved until the microSD card is full.
- You will receive notifications on your phone
• If no microSD is inserted, or if the microSD card is full:
- No clips will be saved.
- You will receive notifications on your phone, then open the app to view live video (with option to save
to mobile device memory).
Application connection tips
The device will not connect to your Wi-Fi network if the password contains any of the
following characters (" \ ). Please remove those characters from your password if needed.
• This device is only compatible with 2.4 GHz networks.
• Have the password for your Wi-Fi router ready.
• Connect the mobile phone or tablet to same Wi-Fi network the camera will connect to.
Pairing: "Add device" → "Video Surveillance" → "Smart Camera"
Care and cleaning
Do not use any aggressive cleaning agents, rubbing alcohol or other chemical solutions as they
can cause damage to the housing and malfunctioning.
• Clean the product with a fibre-free cloth, slightly dampen if needed.
• Do not apply excessive force to the solar panels during the cleaning process.
Declaration of Conformity (DOC)
Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau hereby declares that this product con-
forms to the 2014/53/EU directive.
Click on the following link to read the full text of the EU declaration of conformity:
www.conrad.com/downloads
Select a language by clicking on a flag symbol and enter the product order number in the search
box. You can then download the EU declaration of conformity in PDF format.
Disposal
a) Product
This symbol must appear on any electrical and electronic equipment placed on the EU market.
This symbol indicates that this device should not be disposed of as unsorted municipal waste
at the end of its service life.
Owners of WEEE (Waste from Electrical and Electronic Equipment) shall dispose of it separate-
ly from unsorted municipal waste. Spent batteries and accumulators, which are not enclosed by
the WEEE, as well as lamps that can be removed from the WEEE in a non-destructive manner,
must be removed by end users from the WEEE in a non-destructive manner before it is handed
over to a collection point.
Distributors of electrical and electronic equipment are legally obliged to provide free take-back of waste.
Conrad provides the following return options free of charge (more details on our website):
• in our Conrad offices
• at the Conrad collection points
• at the collection points of public waste management authorities or the collection points set up by manu-
facturers or distributors within the meaning of the ElektroG
End users are responsible for deleting personal data from the WEEE to be disposed of.
It should be noted that different obligations about the return or recycling of WEEE may apply in countries
outside of Germany.
b) (Rechargeable) batteries
Remove batteries/rechargeable batteries, if any, and dispose of them separately from the product. According
to the Battery Directive, end users are legally obliged to return all spent batteries/rechargeable batteries; they
must not be disposed
Batteries/rechargeable batteries containing hazardous substances are labelled with this symbol
to indicate that disposal in household waste is forbidden. The abbreviations for heavy metals in
batteries are: Cd = Cadmium, Hg = Mercury, Pb = Lead (name on (rechargeable) batteries, e.g.
below the trash icon on the left).
Used (rechargeable) batteries can be returned to collection points in your municipality, our stores or wherever
(rechargeable) batteries are sold. You thus fulfil your statutory obligations and contribute to environmental
protection.
Batteries/rechargeable batteries that are disposed of should be protected against short circuit and their
exposed terminals should be covered completely with insulating tape before disposal. Even empty batteries/
rechargeable batteries can contain residual energy that may cause them to swell, burst, catch fire or explode
in the event of a short circuit.

Technical data

a) General
Input voltage / current ........................... 5 V/DC, 2 A
Rechargeable batteries ........................ L i-Ion, 3.7 V 2600 mAh (type 18650)
1 to 4 pcs
Operating current .................................. 250 mA (day mode)
450 mA (night mode)
Charging time ....................................... 6 - 8 hrs (USB), 27 h (solar panel)
Standby power consumption ................ 130 µA
Audio .................................................... 2-way (microphone and speaker)
Resolution ............................................. HD 1920 x 1080 p, SD 640 x 360 p
Frames per second ............................... 15 fps
Recording ............................................. Continuous loop (motion activated)
File record size in ................................. 15 s (in motion detection mode)
Until microSD card full (manual recording)
Focal length .......................................... 3.6 mm
Field of view .......................................... 90°
Storage ................................................. MicroSD (max 32 GB)
MicroSD file system .............................. FAT32
Ingress protection ................................. IP66
Cable type ............................................ USB A to MicroUSB
Operating / storage conditions .............. -20 to +50 °C
Dimensions (W x H x D) ....................... 96 x 69 x 203 mm (camera)
Weight .................................................. 580 g (camera)
b) Motion detection
IR LED .................................................. m ax. 10 m range
<10 lux trigger LED
Motion detection ................................... PIR (Passive Infrared)
PIR detection angle .............................. 110°
Detection range .................................... 8 m
c) Wireless connectivity
Bandwidth ............................................. Min. 2 Mbps upload speed
WLAN technology ................................. IEEE 802.11 b/g/n, 2.4 GHz
Frequency ............................................. 2.412 - 2.472 GHz
Transmission power.............................. < 23 dBm
Transmission distance .......................... max. 50 m (line of sight)
d) Solar Panel
Output voltage / current ........................ 5 .5 V/DC, max. 240 mA
Output power ........................................ max. 1.32 W
e) Application software
Supported OS ....................................... Android 4.2 (or higher),
iOS 9.0 (or higher)
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights in-
cluding translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represent the technical status at the time of printing.
Copyright 2022 by Conrad Electronic SE.
of in the normal household
*2207447_v3_1022_02_dm_mh_en
waste.
