Abmessungen
70.5"
(1791 mm)
50.8"
(1290 mm)
18"
(457 mm)
23.1"
(587 mm)
27.5"
(699 mm)
28.5 – 35.5"
(724 – 902 mm)
Befestigungszubehör
1
Vorbereitungen für den Aufbau des Computerwagens.
Werkzeuge für den Aufbau des Computerwagens bereitstellen.
Make sure lift tension is set to minimum setting
by turning the adjustment nut counterclockwise
(towards the minus (-) sign) until it stops.
NOTE: Adjustment may require
40 - 60 revolutions.
9/16"
2
With lift tension minimized, remove the screws that
anchor the riser to the tower. Save the screws for
future use.
CAUTION: DO NOT loosen, tighten or remove
any other nuts or bolts on the riser or top of tower.
Tampering with nuts or bolts may result in an
unstable Cart, leading to equipment damage and/or
personal injury.
3
Notebook anbringen
a
Heben Sie die Arbeitsfl äche an und platzieren Sie das Notebook auf der Ablage.
b
Bringen Sie ein selbstklebendes Klettband auf den Puff ern an und befestigen es auf der Ablage, um das
Notbook in seiner Position zu halten.
a
2
21"
(533 mm)
*
20"
(508 mm)
25.4"
(645 mm)
22.1"
(561 mm)
18"
(457 mm)
21"
(533 mm)
*
Die empfohlene Entfernung zwischen der Ober-
seite der Tastaturablage und der oberen Kante des
Monitors betägt 508 mm.
CAUTION: Riser is
IMPACT HAZARD!
under spring tension.
Rapid rise or fall of
MOVING PARTS CAN CRUSH AND CUT.
riser can occur prior
Minimize Lift Tension BEFORE:
· Removing Shipping Screws
to counterbalancing.
· Removing Mounted Equipment.
Do Not put yourself in
· Shipping Cart
· Storing Cart
path of movable riser or
To Minimize Lift Tension
mounted components
1. Unlock break and lower worksurface to
until riser is properly
lowest position.
2. Turn adjustment nut at top of riser
counterbalanced. Failure
counterclockwise until it stops
(Adjustment may require 40-60 revolutions).
to comply with this
Failure to heed this warning may result in
caution may result in
serious personal injury or property damage!
equipment damage or
For More information and instructions refer to product
guide at www.ergotron.com or contact Ergotron
personal injury.
Customer Care at 1-800-888-8458.
b
888-SV-22FN-00 rev D
6"
(157 mm)
• 9/16"
• 3/8" (10mm)
WARNING
14mm (9/16")
822-050
Turm
Riser
