2. Insert the bolt through the middle handle and upper
handle.
3. Tighten the handle knob onto the bolt.
4. Repeat for left/right side.
3.3 INSTALL THE DISCHARGE CHUTE
Figure 5 - 6
1. Loosen the knob and bolt on the discharge chute
assembly.
2. Align the holes on the discharge chute with the
holes on the lower support.
3. Once you have engaged the discharge chute onto
the chute base, push until you hear a click.
4. Insert the bolt through the holes and tighten with the
knob.
5. Fix the wire by rolling up the clip.
3.4 INSTALL THE CHUTE CONTROL
ROD
Figure 7 - 8
1. Make sure that the discharge chute faces forward.
2. Keep the grip handle up.
3. Push the chute control rod through the slot below
the control panel.
4. Put the end of the chute control rod straight through
the hole of the chute support.
5. Align the holes on the bracket with the holes below
the control panel. Tighten with the bolts.
NOTE
Make sure that the bracket is in the middle of the
spacers.
6. Pull the cable to attach onto bottom of the rod. Align
the holes, insert the bolt through the holes and lock
with the pin.
7. Pull the grip handle back and then turn the grip
handle left and right to make sure that the discharge
chute moves in the desired direction.
3.5 INSTALL THE BATTERY PACK
WARNING
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the engine stops
before you install or remove the battery pack.
• Read, know, and do the instructions in the battery
and charger manual.
NOTE
Install two batteries for operation or three for extended
runtime.
English
Figure 9
1. Open the battery lid.
2. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
3. Push the battery pack into the battery compartment
until the battery pack locks into place.
4. When you hear a click, the battery pack is installed.
5. Close the battery door.
3.6 REMOVE THE BATTERY PACK
1. Open the battery lid.
2. Push and hold the battery release button.
3. Remove the battery pack from the machine.
4 OPERATION
Wear eye protection during operation.
4.1 COLD WEATHER OPERATION
The safe battery operation temperature ranges from 1°F
(-17°C) to 113°F (45°C).
Do not store or charge battery outside.
Battery must be charged and stored indoors prior to use
of the machine.
If the machine does not start:
• remove the battery pack from the machine,
• charge the battery pack to 15 minutes in warm area,
or when the charging light turns green.
• Install the battery pack back in the unit.
4.2 USE OF CONTROL PANEL
Figure 2, 12
