Cramer 2600186 Bedienungsanleitung Seite 9

5.5 REPLACE THE SAFETY PIN
Figure 20 - 21
NOTE
The safety pin is used to disperse the pressure of
snow to protect the auger/impeller bar.
1. Remove the nuts and safety pins.
2. Install the new safety pins. (The spare safety pins
are on the top of the chute support.)
5.6 REPLACE THE DRIFT CUTTER
Figure 22 - 23
1. Remove the batteries.
2. Insert the two bolts into the intake housing wall.
3. Install the drift cutter and wing nuts onto the bolts.
4. Pre-tighten the wing nuts and keep the drift cutter a
little loose for adjustment.
5. Move the drift cutter to the desired position and
tighten the wing nuts.
5.7 STORE THE MACHINE
• Clean the machine before storage.
• Make sure the motor is not hot when you store the
machine.
• Make sure that the machine does not have loose
or damaged parts. If it is necessary, do these steps/
instructions:
• Replace the damaged parts.
• Tighten the bolts.
• Speak to a person at an approved service
center.
• Store the machine in a dry area.
• Make sure that children cannot come near the
machine.
6 TROUBLESHOOTING
Problem Possible
cause
The handle The bolts
is not in posi- are not en-
tion. gaged cor-
rectly.
The machine The battery
does not is not charg-
start. ed.
The switch
is defective.
English
Solution
Adjust the height of the
handle and make sure
that the knobs and bolts
are aligned correctly.
Charge the battery by fol-
lowing the procedures in
the battery and charger
manual.
Have the switch replaced
by an authorized service
center.
Problem Possible
cause
Battery is
too cold.
Blue LED
light is
Flashing -
Battery is in
Low Voltage
Protection.
Blue LED
light is al-
ways on -
Battery
Temperature
is Low.
Battery may
require serv-
ice or re-
placement.
The engine The belt is
is on, but the damaged.
impeller does
not turn.
A thin layer The scraper
of snow is damaged.
stays behind.
* If you cannot find the solution to these problems, call .
9
Solution
Remove battery from
snow thrower. Place bat-
tery on charger and al-
low to charge for 10 mi-
nutes or until the chang-
ing light turns green. Re-
move from charger and
install in snow thrower for
use.
Bring the Battery and
Charger in to a warm
area. Place the Battery
in the charger and al-
low for the battery to
reach room temperature
or when the light on
the charger is flashing
Green. Once charger is
flashing green, take the
battery and place it in the
unit to begin work.
Bring the Battery and
Charger in to a warm
area. Place the Battery
in the charger and al-
low for the battery to
reach room temperature
or when the light on
the charger is flashing
Green. Once charger is
flashing green, take the
battery and place it in the
unit to begin work.
Call toll free helpline, at
or replace battery.
Replace the belt.
Replace the scraper.
EN
