EN
Button explanation
1. ON/OFF
Short press to turn on/off the light. Long press 5 seconds for code clearing/checking.
When the code is successfully matched, the blue light of the lamp flashes quickly 5
times, and the yellow light flashes slowly 5 times after the code is successfully cleared.
Note: Code clearing/code matching requires holding down the key within 20 seconds
after the lamp is powered on. If no operation is performed after 20 seconds, the
software will exit the code clearing/code matching mode. ( see below steps 1-3).
2. Play/pause
Short press function: When the light strip is turned on, short press to change the
monochrome color or illusion static color enters automatic playback mode. When the
light strip is in dynamic mode, short press the button to pause.
3. Color adjusting ring
Short press or slide the color ring to switch colors in color light mode, and switch color
temperature in white light mode.
4. Light mode
Short press function: Short press the white light switch button to get into the light
mode, the light color will switch among cool, warm and neutral light every click.
5. Timed shutdown
Short press function: Short press the button, the white light flashes one/two/three/four/
five times that mean the light will turn off after one/two/three/four/ five hours later.
6. Mode change speed+/-
Short press the button to change the 256 types illusory color modes and can adjust
the color sequence in setting mode.
7. Music rhythm mode
Short press function: Short press the button to get into the music rhythm mode, click
the button again to switch the mode; then click color adjusting ring, white light switch
and mode change speed+/- to exit. Long press Function: The controller will force the
Wi-Fi pairing state, Lamp with pairing state will appear red light flashing rapidly.
Note: When the power supply is connected, long press the "Music" button for 5-8
seconds in the power on/off state, the Internet data of the lamp will be cleared, and
the WIFI pairing mode will be re-entered. Note: The music rhythm mode has the
highest control power. Please exit music mode when it is not in use or it will switch to
APP built-in microphone mode when using a remote control.
8. Brightness +/-
Short press the button to adjust to 16 levels different brightness.
9. Mode change speed+/-
Short press the button to switch to 10 levels light color changing speeds. And it can
adjust LED set numbers in setting mode.
10. Microphone sensitivity+/-
Short press the button to adjust the microphone sensitivity.
11. Indicator
The light will turn on when the remote control is in normal operation, and if make the
long press, the light will turn of only after a moment.
Use one remote control to operate 1 or more lamps at the sae time
One remote control can be used with 1 lamp OR with multiple lamps at the same time.
You can "pair" it within a range of <5 meters from the lamp(s). To pair and use the
remote control with more than 1 lamp in the same/multiple rooms/spaces (optional to
purchase more lamp sets separately at www.flinqproducts.nl)
Works as follows:
Note: In this process, be sure to turn off other purchased lamps FIRST before pairing.
You must do this by unplugging the adapter.
Below steps 1-3 needs to be done WITHIN 20 seconds time:
1. Plug the adapter into the power outlet of the lamp you want to pair and make sure
the lamp is ON.
2. Put the lamp into "color mode" by pressing the "light switch" button once if the lamp
is in normal white color mode.
3. Press and hold the LIGHT SWITCH button until the lamp slowly flashes the light 5x in
the color WHITE to confirm that the lamp is paired for use with more than 1 lamp.
4. Now remove the adapter OUT of the socket.
5. Repeat steps 1-3 above for any additional other lamp(s)
FlinQ Smart Indoor Xyro Floorlamp
