Magnification: 40x, 100x, 400x, 1000x
Object stage: x-y mechanical stage, 140 mm x
140 mm, with object guide, adjustment range 75
mm x 50 mm
Illumination: Adjustable 6 V, 20 W halogen lamp
integrated in base. Universal 100 V to 240 V,
50/60 Hz power supply
Condenser: Abbe condenser N.A.1.25 with iris
diaphragm , filter holder and filter, focussed via
rack and pinion drive
Camera sensor: 1/3" CMOS, 1.3 Mpixel, colour
prints
Power supply: via USB 2.0
System
requirements:
Vista, WIN7 and WIN8
Dimensions: 220 x 180 x 390 mm³ approx.
Weight: 8.5 kg approx.
3. Unpacking and assembly
The microscope is packed in a molded styro-
foam container.
•
Take the container out of the carton remove
the tape and carefully lift the top half off the
container. Be careful not to let the optical
items (objectives and eyepieces) drop down.
•
To avoid condensation on the optical com-
ponents, leave the microscope in the original
packing to allow it to adjust to room tem-
perature.
•
Using both hands (one around the pillar and
one around the base), lift the microscope
from the container and put it on a stable
desk.
•
The objectives will be found within individual
protective vials. Install the objectives into the
microscope nosepiece from the lowest
magnification to the highest, in a clockwise
direction from the rear.
•
Put the head onto the top of the stand and
tighten the head-lock-screw. Insert the eye-
pieces into the tube.
4. Operation
4.1 General information
•
Set the microscope on a level table.
•
Place the object to be observed in the center
of the object plate. Use the clips to fasten it
into place. Make certain that the specimen is
centered over the opening in the stage.
•
Connect the mains cable to the net and turn
on the switch to get the object illuminated.
•
Adjust the interpupillary distance so that one
circle of light can be seen.
All manuals and user guides at all-guides.com
•
•
•
NOTE: It is best to begin with the lowest power
objective. This is important to reveal general
structural details with the largest field of view
first. Than you may increase the magnification
as needed to reveal small details.
WIN2000,
WINXP,
(oil) objective is chosen, objective oil must be
dripped onto the slide.
To determine the magnification at which you are
viewing a specimen, multiply the power of the
eyepiece by the power of the objective.
•
•
•
•
•
•
•
•
•
4.2 Installation of the software
•
•
4.3 Displaying images on the computer
•
•
2
Make the necessary eyepiece dioptre ad-
justments to suit your eyes.
To obtain a high contrast, adjust the back-
ground illumination by means of the iris dia-
phragm and the variable illumination control.
Rotate the nosepiece until the objective with
the lowest magnification is pointed at the
specimen. There is a definite "click" when
each objective is lined up properly.
Adjust
the
coarse-focusing-knob
moves the stage up until the specimen is fo-
cused. Be careful that the objective does not
make contact with the slide at any time. This
may cause damage to the objective and/or
crack your slide.
Adjust the fine-focusing-knob to get the im-
age more sharp and more clear.
Colour filters may be inserted into the filter
holder for definition of specimen parts.
Swing the filter holder out and insert colour
filters.
Use the knobs of the mechanical stage to
move the slide side-, back- and forwards.
The vernier provides accurate location of the
specimen area.
Always turn off the light immediately after
use.
Be careful not to spill any liquids on the mi-
croscope.
Do not mishandle or impose unnecessary
force on the microscope.
Do not wipe the optics with your hands.
Do not attempt to service the microscope
yourself.
Insert the installation CD into the computer's
CD drive.
Follow the installation instructions (see also
the description of the software on the instal-
lation CD).
Connect the microscope to the computer
using the USB cable.
Start up the software.
When 100x
which
