3. Parts list

Check whether all parts mentioned below are included in the packaging.
1. Door frame 1 pce
2. Door panel 1 pce
3. Gate frame 2 pcs
4. Release button 1 pce
5. Left upper corner 1 pce
6. Right upper corner 1 pce
7. Upper hinge of the door 1 pce
8. Lower hinge of the door 1 pce
4. Assembling the gate
Step 1 : Determine the space where this gate must be placed. The barrier is suitable for openings from 97,2 cm.
to 181.1cm
Wall
22
Metalen hekje voor open haard (3P)
01 02 43XX
Kamin Sicherheitsgitter (3P)
9. Upper door latch 1 pce
10. Lower door latch 1 pce
11. Removable bar 2 pcs
12. Upper bracket 2 pcs
13. Lower bracket 2 pcs
14. Push-button 2 pcs
15. Upper wall hook 2 pcs
16. Upper pin 2 pcs
Wall
Stairs or opening
Kinderpark met verstelbare bodem
Laufgitter mit verstelbarer Boden
Wall
Barrière pour cheminé (3P)
Parc enfant avec fond réglable
Safety barrier for open fi res (3P)
Playpen with adjustable bottom
17. Lower wall hook 2 pcs
18. Lower pin 2 pcs
19. Template 1 pce
Stairs or opening
Wall
