MINI FIL 08B
Ref.No.
13
1
2
4 (5-9)
5
6
7
14
8
9
10 (5-7,
15
9,11)
12
11
16
12 (6-9,
13-17)
13
14
17
15
16
17
6
18
7
19
8
20
21
9
22
23
24
25
A
OPTIONAL ACCESSORIES
3
20
26 (27,28)
–
–
m
Parts included in "Service kit A" – 9090 2038 90
Atlas Copco Tools – No. 9836 1335 00
Ordering No.
N.B. Qty
Description
–
1
Housing
–
1
Protective cover
9092 0065 71
1
Bowl compl., manual
drainage
–
1
Bowl
–
1
Valve
–
1
O-ring (5.5x1.5)
–
1
Seal ring
–
1
Grip piece
9092 0066 01
1
Bowl compl., semi-autom.
drainage
–
1
Spring
9092 0066 31
1
Metal bowl compl., manual
drainage
–
1
Bowl ring
1
Metal bowl
–
m
1
O-ring (31.47x1.78)
–
1
Sight glass
–
m
1
O-ring (28.8x1.6)
9092 0064 81
1
O-ring (35x2)
–
1
Separator disc
9092 0063 31
1
Filter. Approx. 15µm
–
1
Splash shield
2
Plug
–
2
Protective cover
–
1
Protective cover AC No.
–
1
Protective cover AC type
9090 2038 90
Service kit
9092 0063 91
–
Bowl guard
9092 0063 61
–
Filter. Approx. 3µm
9092 0063 01
–
Wall mounting bracket kit
9092 0062 71
–
Assembly kit.
filter to other unit (regulator,
lubricator).
9092 0064 51
–
Air distributing block kit.
Including assembly kits.
