Minimum airflow
for cooling Limit for minimum airflow with cooling can be set in a menu.
See more in the section "commissioning".

1.2 Positioning and fitting of the MXHP module

Fitting the MXHP
module
Step
1 Fit the module using the screw holes in each corner of the module's
mounting box
2 Position the module in the vicinity of:
- a cooling vent or
- the cooling unit control system panel
3 Position the temperature sensor in the supply air duct after the
cooling coil
Action
4/78
