Introduction

Thank you for purchasing the Panasonic product.
This is the Cradle for the Panasonic CF-U1 computer series*
In combination of the computer and Cradle, you can connect variety of devices.
In addition, battery charging is possible.
1
* Not compatible with other products.
Cradle ........................................... 1
E
Cradle Driver CD-ROM ................ 1
: Refer to the on-screen manuals.
Specifi cations
Item
Power Supply Input
Battery Charging Slot
Expansion Bus Connector
LAN Port
USB Port
Output
Serial Port
External Display Port
Dimensions (width ×
depth × height)
Weight
Operating temperature/
Humidity range
6
DC 16 V [Do not use other than the specifi ed AC
adaptor (Model No. CF-AA1633A).]
2 slots
19-pin
IEEE 802.3 10Base-T / IEEE 802.3u 100Base-TX
(4-pin, USB 2.0) × 3
When the AC adaptor is connected: High-power Port
(4.75 to 5.25 V; 500 mA per port)
When the AC adaptor is not connected: Low-power Port
(4.4 V; 240 mA total for all three ports)
(Dsub 9-pin male) × 1
(Mini Dsub 15-pin female) × 1
243 mm × 215 mm × 92 mm {9.57" × 8.47" × 3.62"}
Approx. 1.2 kg {2.65 lb.}
5 °C to 35 °C {30 °F to 80 °F}/
30 % RH to 80 % RH (no condensation)

ENGLISH

1
.

Operating Instructions

(This book) ................................... 1
