Anleitung MSB 28 SPK1 14.10.2005
GB
combustion chamber.
3. Clean and gap spark plug or install a new spark
plug with proper gap.
4. Prepare unit for operation.
5. Fill fuel tank with proper fuel / oil mixture. See
Fuel and Lubrication Section.

TECHNICAL SPECIFICATIONS

Engine type: Air cooled 2-stroke engine,
cylinder hard-chromium plated
Displacement
Power: 0.75 kW / 1 HP
Dry weight
Fuel capacity 520 ccm
Guide bar length
Cutting width with twin line
Line diameter
Cutting width with cutting blade
Cutting blade
Handle "Bike" handle
Ignition Electronic

Trouble shooting the engine

PROBLEM PROBABLE CAUSE
Incorrect starting procedures.
Unit won't start or starts but will
not run.
Incorrect carburetor mixture
adjustment setting.
Fouled spark plug
Fuel filter plugged.
Incorrect lever position on
Unit starts, but engine has low
choke.
power.
Dirty air filter.
Incorrect carburetor mixture
adjustment setting.
Incorrect carburetor mixture
Engine hesitates.
adjustment setting.
Incorrectly gapped spark plug.
No power under load.
Runs erratically.
Smokes excessively.
Incorrect carburetor mixture
(after approx. 1 min. in full adjustment setting.
throttle position)
Incorrect fuel mixture.
26
All manuals and user guides at all-guides.com
13:04 Uhr Seite 26
Spark plug Champion RDJ 8J
Drive Centrifugal clutch
LPA sound pressure level
LWA sound power level
Vibration
max. RPM with twin line
max. RPM with cutting blade
Idle speed
Petrol consumption
3
28 cm
5.8 kg
147 cm
43 cm
2.5 mm
23 cm
4 teeth

CORRECTIVE ACTION

Follow instructions in the User
Manual.
Have carburetor adjusted by an
Authorized Service Center.
Clean / gap or replace plug.
Replace fuel filter.
Move to RUN position.
Remove, clean and reinstall filter.
Have carburetor adjusted by an
Authorized Service Center.
Have carburetor adjusted by an
Authorized Service Center.
Clean / gap or replace plug.
Have carburetor adjusted by an
Authorized Service Center.
Use properly mixed fuel (40:1
mixture).
103 dB(A)
113 dB(A)
2
11.41 m/s
-1
8500 min
-1
11,000 min
-1
3050 ± 350 min
620 g/kWh
