simu MSR Serie Montageanleitung Seite 6

Wiring : MSR +
2
Initialisation of limit switches required
3
3.1
3.3
4
1
2
2 / 4
Unipolar switch
1
2
3
Bipolar switch
1
2
3
OK
clic...
1
2
3
- Mandatory
5
1
3
6 5
2 1
4 3
- Turn the roller tube by hand in the
shutter down direction; You ought
to hear a click. Otherwise, repeat
operation 1.3, 1.4 and 3.1
- Keep key pressed until the motor starts making a clicking
noise.
N
Neutral : Blue
L
Phase : Brown
L
N
PE Earth : green / yellow
PE
- The cable may only be
connected to the motor by
qualified personnel.
- The connector is to be assem-
L
bled without damaging the
N
contacts.
PE
- The continuity of the earth
connection must be ensured.
