sion nozzle and turn counter-clockwise.
To prevent the extension nozzle from ro-
tating around its axis, it is necessary to
move the slider on top of the cleaning
gun (Fig. 52).
Install the coarse filter (supplied), con-
nect the water supply hose (not supplied)
to the water inlet (Fig. 48) and turn on the
water supply.
A high pressure washer with a connect-
ed water supply hose (1) and a high-pres-
sure hose
(2) is shown in Fig. 49. Depending on your
washer, the water inlet can be located at
the front or back of the washer.
There is also a self-suction feature avail-
able, which makes the high pressure
washer independent of the water supply
and makes it possible to use water from
open tanks, for example, from rainwater
tanks or ponds. To begin, immerse the in-
take hose in water and let it fill with wa-
ter. Connect the water intake hose to the
water inlet fitting with the installed filter
(Fig. 50).
Turn the switch to the „ on „ position.
Connect the cleaning gun to the high
pressure hose and get to work.
If water does not flow from the cleaning
gun after 30 seconds, it is necessary to
turn off the pressure washer in order to
avoid damage to it and try again. If the
water does not flow again, find out the
reason using the „ Troubleshooting„ sec-
tion or contact the service center.
The water supply hose must have an in-
side diameter of at least ½ inch (12.7 mm)
or another hose of the required length
with the necessary connector (adapter).
The working pressure at the washer inlet
must be no more than 8 Bar/0.8 MPa and
a capacity of at least 7 l/min for the PW-
14B (2021) washer or 7.5 l/min for the PW-
16B (2021) and PW-16BR (2021) washers.
The temperature of the incoming water
should not exceed +50 °C.
EU-PW0923001-0923001
7. WORKING WITH A HIGH
PRESSURE WASHER
WA R NI NG!
Do not direct the high-pressure wa-
ter jet at people, animals, switched
on electrical equipment or the ap-
pliance itself.
Install the required nozzle. Connect the
power cord of the pressure washer to
the mains and then turn the switch to the
"ON/I" position.
The pressure washer will start pumping
water into the system (approximately a
few seconds). Once the pressure wash-
er has pumped in enough water, the Auto
Stop function will activate and the appli-
ance will stop (this function saves water
and energy). Remove the spray gun trig-
ger lever from the safety catch. Press the
trigger lever on the cleaning gun and
wait until all air plugs have been released
from the system (approximately less than
1 minute) and start the cleaning process.
When the trigger lever on the spray gun
is pressed, there is a possibility of a sud-
den kickback, which will cause the spray
assembly to rotate.
Hold the spray gun at least 30 cm away
from the surface. Direct the water jet
from top to bottom.
When you are finished, release the spray
gun trigger and follow the instructions in
"End of work".
Move the pressure washer using the
transport handle. Do not place the pres-
sure washer horizontally (Figure 22).
Never pull the pressure washer by the
hoses or power cord. Before moving the
pressure washer, stop operation by re-
leasing the spray gun trigger lever.
Use of detergents
For detergents, use a tank or a special
foaming nozzle on the cleaning gun.
en
15
