Use of alternative water sources,
self-priming function PW-18Ri (2021)
The pressure washer is designed to suck
water from open containers, such as rain-
water tubs or ponds. First, immerse the
water intake hose in water and allow it to
fill with water (Fig. 18).
WARN ING!
If there is a crack in the water in-
take hose, the pressure washer will
not be able to suck in water.
Connect the water hose to the water in-
let of the pressure washer (Fig. 19). Turn
the spray gun switch to the "on" position
(Fig. 20).
If no water flows from the spray gun after
30 seconds of switching on, turn off the
pressure washer to avoid damage and try
again. If the water does not flow again,
refer to the Troubleshooting section to
find out the cause or contact a service
center.
Turning on/off
To turn on the pressure washer, turn the
switch to the "ON/I" operating posi-
tion. To turn it off, turn the switch to the
"OFF/0" position (Fig. 21).
The motor is equipped with overheating
protection. If the motor begins to over-
heat, the power supply circuit will open.
Turn off the pressure washer. Allow the
motor to cool for about 30 minutes be-
fore turning it back on. If the problem re-
curs, contact a service center.
Power cable holder PW-14B (2021),
PW-16B (2021), PW-16BR (2021)
Connect the holder (1) to the bracket on
the washer body from the right side (2),
passing it along the guide slots from top
to bottom (Fig. 38). After completing the
work, the power cable must be wound on
the holder.
Holders for the cleaning gun
PW-14B (2021), PW-16B (2021),
PW-16BR (2021)
The holder for the cleaning gun (Fig. 39)
consists of two separate parts, on the
lower and upper parts of the high pres-
sure washer. The holder is intended for
14
temporary storage of the gun during
work breaks.
Install the lower holder in the special
holes in the lower right part of the wash-
er (Fig. 40).
Install the upper holder in the special
splined connection in the upper right
part of the washer. Fix the holder with the
screw included in the kit (Fig. 41).
Unwind the power cable to its full length.
Make sure that the power switch on the
washer body is in the „OFF/0 „ position
(Fig. 42).
For the PW-16BR model, which has a coil
with a high-pressure hose, it is necessary
to transfer the handle of the coil from the
fixed position (Fig. 43) to the working po-
sition.
To do this, press the handle from the in-
side of the coil in such a way that the han-
dle goes all the way out and is fixed with
the help of two latches (2) located on the
handle (Fig. 44).
Connecting a high pressure hose
Connect the high pressure hose to the
washer outlet (Fig. 45) for:
- Models PW-14B (2021),
- Models PW-16B (2021).
Unwind the hose from the coil for model
PW16BR (2021).
Connect the high pressure hose to the
cleaning gun (Fig. 46). During connection,
a characteristic click of the latch should
be heard. If you don't hear a click, try a lit-
tle harder. If the click is not heard during
any manipulations, the latch may be dam-
aged. It is forbidden to use such a device.
For repair, contact the manufacturer (DNI-
PRO M LLC), DNIPRO-M authorized ser-
vice center, or the seller of the product.
To disconnect the high-pressure hose
from the gun, press the lever (1) (Fig. 46)
and pull the hose.
Connection to water supply sources
PW-14B (2021), PW-16B (2021),
PW-16BR (2021)
Insert the extension nozzle into the clean-
ing gun with a little force and turn clock-
wise until the two parts are connected
(Fig. 47). To disconnect, press the exten-
EU-PW0923001-0923001
