Operation / Light Functions - Seto WORKLITE-MINI Gebrauchsanleitung

WARNING!
Charging must only be carried out in dry rooms.
Light function
Press and hold the on / off button (D) to switch the main light on
or off.
The button for light adjustment (G) can be used to select
between warm, cold and mixed light modes.
Press once: main light (warm white)
Press twice: main light (cold white)
Press three times: main light (mixed white) – 100 %
Press four times: flashing light SOS (red)
The respective brightness level for the selected light mode can
be set via the button for brightness setting button (C), which
must be pressed after the button for light setting (G). Switching
between the two brightness levels is done by repeatedly pressing
the button (C).
Capacity indicator
The current status of the rechargeable battery is shown
to you by the capacity indicator (B) on the top rear of
the luminaire during the charging process.
ATTENTION!
• The outer housing of the luminaire may become warm during intensive use. This is normal.
• Do not use the luminaire near high temperatures such as fire or heaters. This may cause an explosion or ignition.
• Do not use if the operating temperature range (-10 to +40 °C) drops below or is exceeded.
• The rechargeable battery may only be used with a suitable charger.

Operation / light functions

– 100 %
– 100 %
– 100 %
Main light (warm white) 100 % Main light (warm white) 50 %
Main light (cold white) 100 % Main light (cold white) 50 %
Main light (mixed white) 100 % Main light (mixed white) 50 %
Flashing light (red) 100 %
100 %
75 %
50 %
25 %
OFF
11
