Stobag S2160/2 Installationsanleitung Seite 5
Vorschau ausblenden
Andere Handbücher für S2160/2:
- Installationsanleitung (5 Seiten) ,
- Montageanleitung (20 Seiten)
Werbung
K1
W1
A1
K2
a
b
c
d
e
400cm 6 x S332
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a
13
13
13
13
W1 b
30
30
30
30
A1 c 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183 183
K2 d
---
---
---
---
W2 e 244 250 256 263 269 273 281 288 294 300 306 313 319 325 331 338 344 350 356 363 369 375 381 388
K3 f
264 270 276 283 289 293 301 308 314 320 326 333 339 345
A2 g 384 390 396 403 409 413 421 428 434 440 446 453 459 465 471 478 484 490 496 503 509 513 521 528
K4 h
---
---
---
---
W3 i
443 455 468 480 493 505 518 530 543 555 568 580 593 605 618 630 643 655 668 680 693 705 718 730
K5 j
463 475 488 500 513 525 538 550 563 575 588 600 613 625
A3 k 583 595 608 620 633 645 658 670 683 695 708 720 733 745 758 770 783 795 808 820 833 845 858 870
W4 l
612 625 637 650 662 675 687 700 712 725 737 750 762 775 787 800 812 825 837 850 862 875 887 900
500cm 6 x S332
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a
13
13
13
13
W1 b
30
30
30
30
A1 c 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203 203
K2 d
---
---
---
---
W2 e 234 240 246 253 259 265 271 278 284 290 296 303 309 315 321 328 334 340 346 353 359 365 371 378
K3 f
---
---
---
---
A2 g 394 400 406 413 419 425 431 438 444 450 456 463 469 475 481 488 494 500 506 513 519 525 531 538
K4 h
---
---
---
---
W3 i
423 435 448 460 473 485 498 510 523 535 548 560 573 585 598 610 623 635 648 660 673 685 698 710
K5 j
---
---
---
---
A3 k 583 595 608 620 633 645 658 670 683 695 708 720 733 745 758 770 783 795 808 820 833 845 858 870
W4 l
612 625 637 650 662 675 687 700 712 725 737 750 762 775 787 800 812 825 837 850 862 875 887 900
