CONTROL UNIT
2.

ELECTRICAL INSTALLATION AND CONNECTING UP

Complete all mechanical installation before you start the installation of electrical components and connecting up.
Installation consists of the following steps:
FITTING ELECTRICAL EQUIPMENT (sect. 2.1).
CONNECTING UP (sect. 2.2 and 2.4).
CONNECTING UP TO 230V MAINS POWER SUPPLY (sect. 2.3).
STARTING THE SYSTEM with SELF-TEACH (sect. 3.1 and 3.2).
RECOGNITION OF REMOTE COMMANDS (sect. 3.2A and 3.2B) (before or after self-teach).
FUNCTIONAL TESTS AND ADJUSTMENTS (sect. 3.3).
ADVANCED PROGRAMMING AND RESET (where necessary) (section 4.1 / 4.2).
2.1

FITTING ELECTRICAL EQUIPMENT

Before you install components you should prepare the electrical connections of the control and safety devices of the
system. Follow the instructions given on the
operator. Follow the instructions given in this manual and the instructions given on components already installed.
!
Warning
The system must only be installed by skilled personnel qualif ed in compliance with the
regulations of the country of installation (CEI 64 - 8 and EN 60335-1 standards).
2.2

CONNECTING UP

Switch OFF the mains power supply before you start connecting up.
Make the connections as shown in Fig.1, sect. 2.4. Check that the cables are connected to the correct inputs. Check
that the minimum cable section is as specif ed.
!
Warning
Faulty connections can cause equipment operating faults and may seriously damage the equipment.
Failure to connect up the equipment correctly will void your guarantee. Do not use intercom or telephone cable.
IMPORTANT: Complete all connections and checks before you connect up to the 230 V AC mains power
supply.
The equipment must be earthed. Connect the earth to the earth terminals.
2.3

CONNECTING UP TO THE MAINS POWER SUPPLY

POWER SUPPLY - 230 V AC MONOPHASE 50/60 Hz.
Use a power supply cable with 3 wires and a minimum section of 1.5 mm
regulations. Choose the section of the cable to match the length of the line.
IMPORTANT! Always install, upstream of the line, a mains switch which guarantees a multipole cut-off with
minimum contact opening of 3 mm (connect it to a 6 A differential overload switch with sensitivity of 30 mA).
When you power up the unit for the f rst time, the board display will show the number "1" or "0" for a few seconds
depending on the type of operator installed (RAIDER 2500
After this, the f ashing letter "S" will appear to indicate that you must perform the self-teach procedure (see sect. 3.1).
