General Safety Instructions - LaserLiner EvolutionCross-Laser 8P PowerBright Bedienungsanleitung

High-precision cross-line laser with 8 super-bright laser lines,
plumb laser and additional slope function.
– Homogeneous 360° laser line: The 4 horizontal laser diodes project a homo-
geneous laser line. This enables the device to be used like a rotary laser.
– Additional slope function to align angled surfaces – motorised inclination of
± 2,5° possible.
– A simple, precise plumb function is afforded by the additional plumb laser
at the bottom and the laser cross at the top.
– Out-Off-Level: is indicated by optical signals when the unit is outside its self-
levelling range.
– The pivoted housing can be turned with a vernier adjustment mechanism
and a horizontal circle to permit exact positioning of laser lines.
– Self-levelling range 2,5°, precision 1 mm / 10 m.

General safety instructions

Caution: Do not look directly into the beam. Lasers must be kept out of
reach of children. Never intentionally aim the device at people. This is a quali-
ty laser measuring device and is 100% factory adjusted within the stated tole-
rance. For reasons of product liability, we must also draw your attention to
the following: Regularly check the calibration before use, after transport and
after extended periods of storage. We also wish to point out that absolute
calibration is only possible in a specialist workshop. Calibration by yourself is
only approximate and the accuracy of the calibration will depend on the care
with which you proceed.
This is a precision instrument which must be handled with care. Avoid
!
impacts and jarring. Store and transport the instrument in its case!
Turn off the unit when it is not in use! Clean with a soft cloth and
glass cleaner.
12
GB
Laser radiation!
Do not stare into the beam
or observe it directly with
optical instruments.
Class 2M laser
< 5 mW · 635-650 nm
EN 60825-1:2007-10
