Comunello Automation CU 24V 2M ONE Installations- Und Gebrauchsanleitung Seite 5

1 MOTOR CONFIGURATION
FORT
MOTOR 1 OUTPUT:
RED ON + BLACK ON –
FORT opens to LEFT
INV1
Inner side view
FORT opens to RIGHT
INV1
Inner side view
1 2 3 4 5 6 7 8 9 10
ENCODER MOT. N.1
