REMARK! Always make sure that the grass basket is properly fixed.
SETTING THE CUTTING HEIGHT
WARNING! Before changing the cutting height setting, turn off the
mower and disconnect the batteries or remove the safety key from
the socket.
The cutting height is adjusted by means of a cutting height lever in six
positions in the range of 25-75 mm.
• Remove the security key.
• Pull the cutting height adjustment lever away from the recess.
• When moving the cutting adjustment lever, select the appropriate
cutting height (Fig. L).
• Place the cutting height adjustment lever in one of the selected bays
of the cutting height adjustment lever lock on the mower housing. When
adjusting, hold the mower with the front handle (Fig.M).
TRANSPORT HANDLE
The mower has a convenient and practical transport handle for carrying on
the housing. The mower should be moved in two people (Fig. N).
WORK / SETTINGS
ON/OFF
WARNING! Before starting, the batteries must be installed. The
device requires the use of 2 batteries otherwise it will not work. For
proper operation of the device, the batteries should be of the same
capacity and with a similar degree of charge. The mower has a safety
key in the battery compartment, which must be placed in the socket
for the device to start working. Failure to place the safety key in the
socket results in the inability to start the mower despite the installed
batteries.
WARNING! Before starting, make sure that the switch is in the off
position and all components are well assembled, as described in this
manual.
ON – OFF
• Lift the battery compartment cover (Fig. O).
• Install the batteries and place the safety key in the slot (Fig. P, R).
REMARK! The mower is equipped with a safety button of the switch
to protect against accidental starting.
The mower has a combined switch with two levers.
Enable
• Press and hold the switch lock button.
• Pull one of the switch levers to the handle and hold (Fig. S).
• Release the pressure on the switch lock button.
Disable
• Release the switch lever and wait for the cutting knife to stop turning.
REMARK! Each time during start-up, press the safety button of the
switch. Never attempt to lock the safety button of the switch or the
switch lever in the on position.
All parts should be properly installed and meet the requirements to
ensure proper operation of the mower. Any damaged safety
component or part should be repaired or replaced immediately.
When the engine is turned off, the cutting elements still rotate.
TIPS FOR SAFE USE
• When mowing long grass, the work should be done gradually, in
layers.
• The mower should be moved in a smooth motion by pushing or pulling
holding the handle with both hands.
• A working mower should be kept away from hard objects and
cultivated plants.
• The mower can only be worked when the grass is dry.
• The mowing speed should be about 1 meter per 4 seconds.
• Empty the grass basket regularly.
• When trying to accurately cover the mowing area, you should be
guided by drawing T.
The mower can be used with or without a grass basket mounted, with a
mulching cap.
WARNING! Do not work with a lawn mower without a basket with
the outlet cover raised.
REMARK! When working with a lawn mower, remember not to expose
the mower with batteries to direct sunlight, especially for a longer break
time, leaving the device unattended. The batteries can heat up a lot
during this time. An increase in temperature can damage both the
battery and the mower. When the critical temperature is exceeded,
spontaneous ignition and even explosion of batteries may occur. Never
expose batteries to direct and prolonged sunlight!
OPERATION AND MAINTENANCE
WARNING! Before proceeding with any installation, adjustment,
repair or maintenance activities, remove the batteries from the device
and disconnect the security key.
CLEANING
• After each mowing operation, the remnants of grass that have
accumulated in the housing of the cutting blade should be removed.
• The engine housing should always be as free from dust and debris as
possible.
• Clean the ventilation gaps in the engine housing to prevent them from
being clogged by grass clippings.
• Wipe the device with a clean cloth or blow it with low-pressure
compressed air.
• Do not use water or chemical cleaners for cleaning
• Care must be taken to ensure that water does not get inside the
device.
• At the end of the work, remove the grass basket and clean thoroughly
to prevent the formation of mold and unpleasant odor.
MAINTENANCE AND STORAGE
• Check that the cutting knife has not been damaged from impacts on
hard objects, if necessary – sharpen or replace the cutting knife.
• Check that the ejection hole into the grass basket is open.
• Check the grass basket for wear and deformation.
• Use only original accessories and original spare parts.
• During storage, the handle can be folded as described above.
• Unused device should be stored in a dry, cool, child-inaccessible
place.
• Store the device with the batteries removed.
• Do not store at temperatures exceeding 40°C
CUTTING KNIFE REPLACEMENT
REMARK! Wait for the cutting knife to stop completely, remove the
batteries from the device and disconnect the safety key. Use gloves
when replacing the knife.
• Disassemble the grass basket.
• Turn the mower "to the side" (fig. U).
• Grasp the cutting knife securely or lock, for example, with a piece of
wood (protective gloves should be used).
• Unscrew the screw fixing the cutting knife with a key by turning left
(Fig. W, Y).
• Replace or sharpen the cutting knife (in the case of replacement with
a new one – the cutting knife must be of the same size and weight).
• Attach the cutting knife as above in reverse order (the holes in the
cutting knife must be mounted on the spindle pins).
• The act of sharpening or replacing a cutting knife is best entrusted to
a qualified person using original parts.
All kinds of defects should be removed by the manufacturer's authorized
service.
SECURITY
The mower is equipped with the following safety systems, disabling the
device in dangerous conditions.
• Overload protection
• Overheating protection
• Protection against excessive battery discharge.
TECHNICAL PARAMETERS
RATINGS
Cordless mower 04-610
Parameter
Supply voltage
Spindle speed without load
Protection
Protection class
Cutting width
Number of cutting height adjustments
Cutting height range
Grass basket capacity
Front wheel diameter
Rear wheel diameter
Mass
Year of manufacture
10
Value
36 VDC
min-1
2800
IPX1
III
400 mm
6
25-75cm
40L
150mm
200mm
18kg
