Setup

DJ Mono (with Two Stacked Cardioid Subs)

*Alternate Connection
This scenario may require a
specialized cable or adapter.
Connect a TRS cable to the
TRS Line Input to allow for a
wider range of volume control.
MUTE MUTE
INST
**Alternate Connection
The L1 Pro32 can be connected to
a Sub1/Sub2 by analog connection.
Two Subs can also be connected
together by analog connection.
When connecting two Subs
together by analog connection,
connect the Line Output of the first
Sub to the Line Input of the second
Sub with an XLR cable. Subs set up
without a SubMatch cable must be
connected to a power source.
18 • English
MUTE
INST
*
**
PRO.BOSE.COM
(Facing audience)
CARDIOID
CARDIOID
(Facing performer)
L1 Pro32 Portable Line Array • Owner's Guide
PHASE/PATTERN
PHASE/PATTERN
LINE IN 1
