Installation- and operating instructions:
Turn the loose included PG9 gland into the, for this purpose provided, thread.
Be careful that the flat gasket fits to the PG gland.
Install the cable protection hose with the help of an (Ü-) bushing nipple and a hose clip. Fur-
thermore pay attention to the properly fit of the seal. (see installation draft point 1)
To avoid contamination of the stainless steel threads and the underwater spotlight interior,
you have to cover them with the enclosed, self-adhesive building protection.
The built-in pot can then be concreted according to the dimensional sketch in the masonry.
(flush pool surface) If there are, despite these measures, contaminations of the threads, they
have to be cleaned with the thread cutter M6/III. The film must be removed for the screw
passage with the help of a hole punch, so that surplus film cannot be grinded down in the
thread.
If the, for this purpose provided, incoming jet function should be activated, the rupture point
must be penetrated and a regular pressure line d 50 or d 63 must be installed. (installation
draft point 2)
When installing the underwater spotlight-insertion, pay attention that enough cable is rolled
up onto it. In this manner a change of the lamp can be carried out without sinking the water
surface. Depending on the mounting depth, there must remain enough cable to lift the spot-
light over the water-line. With the two screws (see installation draft point 4) fix the spotlight-
insert.
ttention:
Use only the designated constant-Power-transformer. (DC 700 m / 12-30 V)
Proper connection of the +/- Pole clamp drawing on the cable and transformer.
To be connected only by a certified electrician.
The spotlight must only be operated underwater.

Technical data:

Power consumption: ~ 15 W Light output: ~ 1080 Lumen
