Measure: Set and edit overlay
Click "Measure" in the icon bar and select the measurement
shapes (overlay elements) from the dropdown listbox.
All measurement shapes in the image can be listed in a
table, which will be displayed when clicking "Show results"
in the dropdown listbox of the button "Measure".
Length / Angle: Set length and angle
unit for the measurement shape.
Merge calibration with image:
Merge the overlay into the image and
save it as part of the image file.
Measurement shape and ID
General style: Set font, font color, line
width and line color for the measure-
ment shape and the caption.
Live form parameter: Select live para-
meter display of the shape.
