Measure Measure
Measure: Create a measurement calibration
First, place the calibration standard on
your microscope.
Calibrations:
the calibration line. Select length or
angle unit in the dropdown listbox.
English
Name:
tion into the text box.
Length:
bration line. This value refers to the
distance referenced by the calibration
line.
General style:
line width and line color.
Correction / Draw:
to modify the existing calibration.
Click "Draw" to draw a new calibra-
tion line.
When clicking "OK", the lower area
of the register card will change and
the data of the current calibration will
be displayed.
Current calibration:
When selecting a calibration in the
dropdown listbox, the data of this ca-
libration will be displayed in the lower
area of the register tab.
14 14
Click "Add" and draw
Insert the name of the calibra-
Insert the length of the cali-
Select font, font color,
Click "Correction"
®
