Dirna Bergstrom bycool compact 1.4 Montageanweisungen Seite 18

COMPACT
EN EN
Place (2) fastening supports, with (1) washer
8a
and (1) M8 self-blocking nut, without
tightening.
8a
Screw 10 mm deep (4) M6 x 55 or 80 studs,
9
where indicated distance (D) in figure point
16.
To place (1) rubber washer diameter 6 (1),
10
plane washer diameter 6 wide wing and (1)
nut M6, over each of the spigots of M6. After,
to tight the nut til the rubber washer remain a
little tight.
8a
(D) mm
18
Air conditioning for vehicles
9
9
plane wide
8a
plane
washer
wing
nut M6
