Mounting to vertical or
horizontal surface:
4x min M10 - M12, or
2x min M12 - M14, or
4x M8 + 1x M20
2x M12
55 Nm
40.6 ft lb
00-52-889 | DOC-0015410 rev D | 03-2022
200/7.9"
121/4.8"
60/2.4"
Ø14,5(2x)
Ø9(4x)
Ø13(4x)
Ø21,5
532/20.9"
0°
www.schreder.com
10°
40
2/5
