1. Safety notes
This unit is constructed for panel and cabinet installation. It complies with the safety
requirements to EN 61010-1 / VDE 0411 Part 1 and has left our works in perfect and
safe condition.
Danger!: Safe operation can only be guaranteed if all hints and warning notes in
these operating instructions are heeded:
• The unit is only to be operated in an installed condition.
• Installation and connection must only be done by skilled and qualified personnel.
Please take care of the local legal access protection requirements.
• Always connect the earth (ground) protection cable before attempting to connect
any other cables. It can be dangerous if this protection cable is interrupted or
broken.
• Before installing please compare the supply voltage with that on the unit legend
plate.
• A switch or power isolator must be installed within reach of the unit. It must also be
identified as a power isolator.
• A power fuse of 10 A must be installed.
• If it is assumed that the unit cannot be safely operated (e.g. visible damage) it must
be immediately taken out of operation and secured against unintentional use
• Repairs must only be done by trained service personnel.
Danger!: The power plug may only be connected to a socket with an integrated earth
(ground) protection point. This earth (ground) protection must not be broken even
when operating using an extension lead.
Relay output: U(max) = 30 V eff (AC) / 60 V (DC)
"Danger!":Ignoring this warning can lead to personal injury !
"Attention":Ignoring this warning can lead to damage of the device or faulty operation
"Hint":Hints for better installation/operation.
2. Check before installing !
Transport damage ?
Please inform both your supplier and shipping agent !
The complete delivery ?
- Unit (with plug-in screw terminal blocks for power and signal connection, dependent
on the order).
- 2 jack screws for panel mounting
- These operating instructions
Please inform your supplier if anything is missing !
1. Safety notes / 2. Check before installing !
1.1 Correct use/safety
notes
Desk top version:
1.2 Danger and hint
meanings:
