DMX Functions

You can control Ray Tracer Quad by linking it to a DMX controller. See the charts of available
functions below.
40-Channel Operation
Channel Function
1 Tilt 1
2 Tilt 2
Dimmer
3
Shutter
4
LED 1 Red Dimmer
5
LED 1 Green Dimmer 000–255
6
7 LED 1 Blue Dimmer
8 LED 1 White Dimmer
LED 2 Red Dimmer
9
LED 2 Green Dimmer 000–255
10
11 LED 2 Blue Dimmer
12 LED 2 White Dimmer
LED 3 Red Dimmer
13
LED 3 Green Dimmer 000–255
14
15 LED 3 Blue Dimmer
16 LED 3 White Dimmer
LED 4 Red Dimmer
17
LED 4 Green Dimmer 000–255
18
19 LED 4 Blue Dimmer
20 LED 4 White Dimmer
LED 5 Red Dimmer
21
LED 5 Green Dimmer 000–255
22
23 LED 5 Blue Dimmer
24 LED 5 White Dimmer
8
Value Description
000–255 Tilt Motor 1, 0° (000) to 150° (255)
000–255 Tilt Motor 2, 0° (000) to 150° (255)
000–255
Dimmer, dark (000) to bright (255). This feature also
affects the automatic programs (Channel 37).
000–007 Closed
008–076 Strobe, slow (008) to fast (076)
077–145 Pulse, slow (077) to fast (145)
146–215
Random strobe, slow (146) to fast (215)
216–255 Open
000–255
LED 1, red dimmer, dark (000) to bright (255)
LED 1, green dimmer, dark (000) to bright (255)
000–255 LED 1, blue dimmer, dark (000) to bright (255)
000–255 LED 1, white dimmer, dark (000) to bright (255)
000–255
LED 2, red dimmer, dark (000) to bright (255)
LED 2, green dimmer, dark (000) to bright (255)
000–255 LED 2, blue dimmer, dark (000) to bright (255)
000–255 LED 2, white dimmer, dark (000) to bright (255)
000–255
LED 3, red dimmer, dark (000) to bright (255)
LED 3, green dimmer, dark (000) to bright (255)
000–255 LED 3, blue dimmer, dark (000) to bright (255)
000–255 LED 3, white dimmer, dark (000) to bright (255)
000–255
LED 4, red dimmer, dark (000) to bright (255)
LED 4, green dimmer, dark (000) to bright (255)
000–255 LED 4, blue dimmer, dark (000) to bright (255)
000–255 LED 4, white dimmer, dark (000) to bright (255)
000–255
LED 5, red dimmer, dark (000) to bright (255)
LED 5, green dimmer, dark (000) to bright (255)
000–255 LED 5, blue dimmer, dark (000) to bright (255)
000–255 LED 5, white dimmer, dark (000) to bright (255)
