Key To Symbols; Technical Features - cherubini RX MINI Einstellanleitungen

Skipper
A
up
B
stop
C
down
POP
up
A
B
stop
C
down
A
Press button A
up
down
Awning
short motor
rotation in one
direction
long motor rota-
tion in the other
direction
double short
rotation

KEY TO SYMBOLS

GIRO
C
A530058 Remote Control
with 4 independent channels
+
A B
Press buttons A and B
at the same time
up
down
Rolling shutter

TECHNICAL FEATURES

- Power supply
- Power consumption
- Radio Frequency
- Decoder System
- Modulation
- Max. number storable transmitters 15
- Max. motor power
- Operating temperature
- Dimensions
- Weight
- Protection degree
A
B
Disconnect the
power supply
Led
22
UP
DOWN
STOP
Button or
commutator, wired
SET
Press button SET
Power up
230 V / 50 Hz
0,5 W
433,92 MHz
Rolling Code
AM/ASK
300 W
-10 C° +55 C°
40x40x20 mm
80 gr
IP44
