Technical Data
Measurands
Relative Humidity [RH]
Measurement range
Accuracy
1)
(incl. hysteresis, non-linearity and repeatability)
Temperature [T]
Measurement range
Accuracy at 20 °C
Calculated parameters
Output
Analogue outputs
General
Supply voltage
From intrinsically safety barrier
Safety factors
Electrical connection
Cable glands
Protection class
Working and storage temperature ranges
Material
Enclosure
Probe
Safety area installation
Electromagnetic compatibility according
1) Traceable to intern. standards, administrated by NIST, PTB, BEV,... The accuracy statement includes the uncertainty of the factory calibration with an enhancement factor k=2
(2-times standard deviation). The accuracy was calculated in accordance with EA-4/02 and with regard to GUM (Guide to the Expression of Uncertainty in Measurement).
Operating manual EE100Ex Humidity / Temperature sensor for intrinsically safe applications
0...100 % RH
±2 % (20...30 °C, 0...90 % RH)
-40...60 °C
(-40...140 °F)
±0.2 °C
(±0.36 °F)
Dew point temperature [Td]
Frost point temperature [Tf]
2 x 4...20 mA, 2 wire, freely selectable and scalable
11 V + R
* 0,02 A < U
< 28 V DC
L
B
Ui=28V; Ii=100mA; Pi=700mW; Ci = 2.2nF; Li ≈ 0mH
Screw terminals, max. 1.5 mm²
M16 for cable diameter 4.5 - 10 mm (0.18 - 0.4")
M20 for cable diameter 10 - 14 mm (0.4- 0.55")
IP65
-40...60 °C
(-40...140 °F)
Aluminium (Al Si9 Cu3)
ABS / PC - wall mount version // PC - remote probes
Gas - Zone 1 / EPL Gb
EN61326-1
Industrial Environment
(R
= load resistor)
L
EN61326-2-3
