| PA-10 EVO INSTALLATION
RCA CONNECTION
The PA-10 EVO can be connected to your
audio system via unbalanced RCA inputs
or balanced XLR inputs. The PA-10 EVO is
DS-10 EVO
GN Link
XLR CONNECTION
Press the BAL button on the rear of the
PA-10 EVO to use the XLR connection.
DS-10 EVO
GN Link
extremely flexible and you can set it up in a
wide variety of configurations, as shown in
the following pages.
PA-10 EVO
SPEAKER RIGHT
SPEAKER RIGHT
4
GN LINK
Control multiple units in
Master-Slave mode by
turning ON/OFF just one.
IN
SPEAKER LEFT
The PA-10 EVO must be
set in BAL.
PA-10 EVO
IN
SPEAKER LEFT
