PRODUCT SETUP

1-2
POLE-MOUNT INSTALLATION
1. Preparation: Plug the
10-meter RJ45 cable
into the device. Pull
the cable through
the connector on the
waterproof plate.
1-3
2. Slide the waterproof
silicone clip assembly
onto the RJ45 cable
and press it into the
plate.
1-4
3. Slide the waterproof
connector cover
onto the silicone clip
assembly.
1-5
4. Turn the connector
cover clockwise to
secure it to the plate.
2
5. Insert the SIM card into
the SIM slot (please
double-check the sim
card size before you put
it in).
1-6
6. Secure the waterproof
plate to the device by
using the M2.5 x 6mm
screws (6 pcs)
DWP-1010K T
