PRODUCT
SETUP
Ensure that your DWR-512 Mobile Router is powered off before performing the steps below.
1. Insert a standard U(SIM) card into the SIM card slot on the back of the router with the gold
2. Insert your Internet/WAN network cable into the WAN port on the back of the router.
Note: The 3.75G connection can also be used as a backup WAN. Once a backup is configured,
3. Insert the Ethernet cable into the LAN Port 1 on the back panel of the DWR-512 Mobile Router,
Note: The DWR-512 Mobile Router LAN Ports are "Auto-MDI/MDIX." Therefore, patch or
4. Connect the power adapter to the socket on the back panel of your DWR-512 Mobile Router.
Open a browser window and enter the IP address below into the browser address field.
Log in using the username and password below.
DWR-512
Downloaded from DWR-512_A1_QIG_v1.00(EU).indd 3 www.Manualslib.com
HARDWARe SetuP
contacts facing downward.
if the Ethernet WAN is not available the router will automatically use 3.75G for the Internet
connection.
and an available Ethernet port on the network adapter in the computer you will use to
configure the unit.
crossover Ethernet cables can be used.
Plug the other end of the power adapter into a wall outlet or power strip.
a. The Status LED will light up to indicate that power has been supplied to the router.
b. The LEDs on the front panel will flash on and off as the DWR-512 Mobile Router performs
initialization and Internet connection processes.
c. After a few moments, if a connection has been established, the following LEDs will turn
solid green: Power, Status, WAN, WLAN, and LAN Port 1 (or whichever port(s) your
Ethernet cable has been connected to).
ADVANCeD SetuP (ACCeSS VIA IP ADDReSS)
manuals search engine
IP ADDRESS: http://192.168.0.1
USERNAME: admin
PASSWORD:
3
