USING THE IS-10
OUTPUT SELECTION
The IS-10 has two audio outputs:
|
SPEAKER OUT (Mono/Stereo)
|
HEADPHONE OUT (High/Low)
Each output features a dedicated amp stage
and the volume level is saved for that output.
Plug in your headphones and the IS-10 will
automatically enable the HEADPHONE OUT.
Remove the headphones and the IS-10 will
switch to SPEAKER OUT.
STEREO AND MONO MODE
When using the speaker output, IS-10 can
work both in:
|
STEREO
|
MONO
When in stereo, the IS-10 delivers 90W per
channel into 8Ω and 4Ω.
The IS-10 can also work in mono when
matched with a PA-10 EVO, increasing the
power delivery to 280W per channel into 8Ω
and 4Ω.
When set to mono, the IS-10 always drives
the LEFT channel while the PA-10 drives the
RIGHT channel.
MUTE CONTROL
To mute or un-mute the audio input, press
twice the SKC.
HEADPHONE OUTPUT LEVEL
When using the headphone output, you can
adjust the output level to match it to your
headphones' requirements. We suggest to
select HIGH if you are using low-sensitivity
headphones, and LOW for high-sensitivity
headphones.
SETTING OUTPUT
LOW 1W
HIGH 5W
BLUETOOTH CONNECTION
Select BLUETOOTH as the input to activate
the Bluetooth connection. The streamer will
appear as "Gold Note" or "IS Gold Note".
To turn off the Bluetooth, simply change the
active input.
AUDIO FORMAT AND INFO
The file format and resolution of the audio
stream are displayed in real-time, including
additional info such as when you are playing
MQA files (the MQA icon shows at the top).
9
HEADPHONE TYPE
High-sensitivity
Low-sensitivity
